Through high-resolution industrial cameras, precision optical lenses, professional vision light sources, and AOI (Automated Optical Inspection) technology, it achieves high-speed, high-precision automated inspection. It can instantly identify various appearance defects in PCB bare boards and PCBA assembly during production, effectively improving inspection efficiency, reducing missed inspection rates, and ensuring product quality and production yield.
PCBA Inspection
After SMT placement and reflow soldering are completed, visual inspection is conducted to ensure component installation and soldering quality meet standards.
Inspectable items：
- 元件缺件（Missing Component）
- 元件偏移（Component Shift）
- 元件旋轉（Rotation）
- 元件極性錯誤（Polarity Error）
- 墓碑效應（Tombstoning）
- 焊橋／連錫（Solder Bridge）
- 少錫／多錫（Insufficient / Excess Solder）
- 虛焊（Cold Solder Joint）
- 浮腳（Lifted Lead）
- 錫球（Solder Ball）
PCB Inspection
After PCB etching is completed, appearance quality inspection is performed to ensure the circuit pattern meets design specifications.
Inspectable items：
- Trace Width / Spacing
- Open Circuit
- Short Circuit
- Nick
- Copper Burr
- Missing Copper
- Pinhole
- Over / Under Etching
- Solder Mask Defect
